Rugged LCD displays have been around for a fairly long time and their uses range from aiding in military and marines operations to the retail, restaurant, hospitality, and medical industries.

Features-
•	Built-in 12.1” TFT Display
•	4:3 aspect ratio
•	High Resolution (640 x 480)
•	High Contrast Ratio
•	High Brightness
•	LED Backlight
•	Brightness- 800 cd/m2
•	Contrast Ratio (Dark Room)- 700:1
•	Dimming Ratio- 400:1 (at least 20 dimming steps)
•	Protections- Reverse Polarity Protection (RPP)
•	Weight- 6kgs

Applications-
•	Military Applications
•	Naval Applications
•	Airborne Applications
•	marines operations

The 15" Keyboard TFT LCD Display which is device under test (DUT) specifically designed to operate with heavy duty environmental specifications dealing with field-of-action/transportation conditions of use and requiring extremely high levels of performance. DUT implements the most drastic requirements set by the military sector, with upper-quality graphic display. It combines the very best electro optical capabilities within such a compact solution. It is EMC reinforced, full MIL Spec class, that insures a perfect readability in the most demanding applications.

15 Inch Keyboard TFT LCD Display is a Rack with slide mount, color active matrix TFT (Thin Film Transistor) LCD (Liquid Crystal Display) display. The main characteristic is that it has an excellent display performance driven by a pure Digital LVDS (Low Voltage Differential Signaling) interface assembled in a compact & slim LED backlight unit. Its outstanding performance high brightness, super wide viewing angle and ultra-high contrast ratio makes this display very suitable for terminal and video application.

Track Ball- The trackball positioned at left hand side in the desktop area, trackball is integrated in the electronics.
Keyboard- The keyboard is backlit keys and industrial silicon rubber keypad.  The Keyboard is engraved with English characters.
Fan- Fan is used for sufficient air circulation to and avoid heating.

ENVIRONMENTAL PERFORMANCE-
•	Front bonded LCD panel
•	Fully sealed & enclosed with MIL circular connectors
•	Surviving high shock and vibration levels
•	Extremely broad operational temperature range
•	Use of green products: no mercury / no cadmium / ROHS compliant

OPTICAL PERFORMANCE-
•	High brightness over the operational temperature range
•	Anti-reflection

SIGNAL PROCESSING PERFORMANCE-
•	High brightness over the operational temperature range accepting up to XGA (1024 x 768).
•	The true 8-bit performance throughout the scaling device, very high-performance scaling engine and advance color management on the board ensure the high pixel density.

GENERAL PERFORMANCE-
•	Compactness
•	Ease of maintenance
•	Ease of implementation
•	High reliability

The 17-inch Rugged LCD display consists of an LCD panel with an integrated LED backlight. The AD controller board and AC-DC power supply are fitted in a specially designed and manufactured rugged enclosure.

It is a color active matrix TFT LCD display, the TFT array as an electro-optical switch regulates the amount of transmitted light from the backlight when it is controlled by the data signals. Color images are created by regulating the amount of transmitted light through the TFT array of red, green, and blue dots.

The AD controller board is a high scaler board of high-resolution TFT LCD panel with a high-quality scaling engine, which can auto-detect the various input format via the analog RGB input port, VGA, S-Video, Composite Video, and DVI-D input port.

The OSD allows for easy adjusting of the characteristics of the image being displayed. All these adjustments (Picture, Sources, Utilities & Setting) are made using the OSD control button on the front panel of the display.

Interfaces
•	1× RGB
•	1 X VGA
•	1 X S-Video
•	1 x C-Video
•	1 x DVI-D
Supports the following video formats: NTSC, PAL

Features-
•	They’re capable of lasting approximately 30,000 hours with continuous use for about 10 hours per day (that’s the equivalent of about 8 years)
•	Touchscreen LCD displays won’t overheat if they’re left on for long periods of time, which is ideal for environments and applications that require ongoing usage (e.g., military and marine ops, retail displays, restaurant digital menus, medical facilities, etc.)
•	Designed and manufactured with high performance standards to withstand extremely harsh weather and usage conditions
•	Dustproof and waterproof to prevent miniscule elements from causing internal damages
•	Sunlight readability and extensive brightness adjustment capability to facilitate usage in all lighting conditions
•	They’re completely shock- and vibration-proof to protect the internal mechanisms from damage caused by external elements
•	They can tolerate a wide range of temperatures from below freezing to extremely hot, depending on the environment

Applications-
•	Military Applications
•	Naval Applications
•	Airborne Applications
•	marines operations

Rugged LCD displays have been around for a fairly long time and their uses range from aiding in military and marines operations to the retail, restaurant, hospitality, and medical industries.

Features-
•	5:4 aspect ratio
•	High Resolution (1280x1024)
•	High Contrast Ratio
•	High Brightness
•	Circular Connectors for power supply
•	Communication Port- USB/RS 232
•	Luminance- 350 cd/m2
•	Contrast Ratio- 1000:1
•	Display Colors- 16.7m color
•	Video I/P- DVI-G & VGA
•	Touchscreen- Resistive/capacitive touchscreen
•	EMI/EMC- MIL STD 461E
•	Vibration- MIL-STD-617-1-Type 1
•	Shock- MIL-STD-901D/MIL-STD-810

Applications-
•	Military Applications
•	Naval Applications
•	Airborne Applications
•	marines operations

1λ UV Fused Silica Windows are precision manufactured using UV-grade synthetic fused silica. In addition to superior transmission, the synthetic fused silica of these optical windows exhibits higher thermal properties, exceptional purity, and excellent environmental durability for demanding applications.

Note: New additions to this product family may be specified with a transmitted wavefront distortion (TWD) specification instead of surface flatness.

Features: -
•	Available uncoated or with broadband anti-reflection coatings
•	Ideal for cost-sensitive broadband applications
•	Sizes ranging from 5mm to 100mm diameter


Technical Specifications: -
(Kindly refer to images) *

Applications: -
•	Submarine glass
•	Barcode readers
•	Military-grade lasers
•	Aerospace windows
•	Endoscopic instruments

The Rugged 20.1" Rugged Display consists of an LCD panel with an integrated LED backlight. The AD controller board and AC-DC power supply are fitted in a specially designed and manufactured rugged enclosure.

It is a color active matrix TFT LCD display, the TFT array as an electro-optical switch regulates the amount of transmitted light from the backlight when it is controlled by the data signals. Color images are created by regulating the amount of transmitted light through the TFT array of red, green and blue dots.

The AD controller board is a highly scaler board of high resolution TFT LCD panel with high quality scaling engine, which can auto-detect the various input format via the DVI-I & VGA.

The OSD allows to easily adjust the characteristics of the image being displayed. All these adjustments (Picture,Sources , Utilities & Setting) are made using the OSD control button on the front panel of the display.

Interfaces-
•	1xDVI-1
•	1xVGA

Electro-Optical Characteristics Or Technical Specifications-
•	Screen Size 20.1 Inch (Diagonal)
•	Panel type a Si TFT‐LCD
•	Viewing 170° (Left & Right), 170˚ (Up & Down)
•	Screen Dimensions 482 mm (L) x 399 mm (H) x 81 mm (D)
•	Panel Resolution 1600 x 1200 Pixels
•	Contrast Ratio 1400:1
•	Active Area 408mm x 306mm
•	Luminance 250 cd/m2
•	Aspect Ratio 4:3
•	Display Color 16.7 M
•	Dot pitch 0.255 mm
•	Response Time 30 msec

FEATURES-
•	Built-in 20.1” Display
•	4:3 Aspect Ratio
•	High Resolution (1600 x 1200)
•	Wide Viewing angle
•	High Contrast Ratio
•	High Brightness

DISPLAY SPECIFICATIONS-
•	Screen Size- 20.1” (Diagonal)
•	Active display area- 408×306 mm (H×V)
•	Brightness- 800 cd/m2 typical
•	Pixel Dimension- 0.255 x 0.255 mm
•	Typical viewing angle- 85° right & left, 85° up & down
•	Resolution- 1600 x 1200 Pixels
•	Contrast ratio- 1400:1
•	Display color- 16.7 M
•	Backlight- LED Technology
•	Response time- 08 msec (Typ)
•	Video Input- DVI-I & VGA HD15
•	OSD Controls- Power, Menu, Auto, Down, Up, Right, Left, SRC
•	Remote Control- RS-232 Port
•	Input Power- 230V, 50Hz, AC
•	Safety- EN 60950
•	Outline Dimension- 483 x 354.8 x 105 mm
•	Weight- <9.5 Kg

ENVIRONMENTAL SPECIFICATIONS-
•	EMI/EMC- MIL STD 461E/F
•	Environmental Test- As per JSS 55555 Standard

Applications-
•	Military Applications
•	Naval Applications
•	Airborne Applications
•	marines operations

The Rugged High-Performance Computing System is a Panel PC Touch screen Single Display Unit. The Rugged High-Performance Computing Systems which have been designed to meet MIL standards in extreme environments and manufactured to a fully functional user interface station for a Surface Ship application.
It provides a presentation of high-resolution graphics and alphanumeric data from weapons and sensors on a 21.5” LCD Monitor of 1920X1080 FHD resolution with sunlight readable feature. The Rugged High-Performance Computing Systems is ergonomically designed as per MIL-STD-1472F to provide the visible functions of the monitor and involve all user interactions. The Console is interfaced with user input devices like keyboards, trackball, indicators, Buzzers, and switches for full-functional processing.

Features-
•	Panel Size- 21.5" Panel PC LCD/LED rugged Touch display
•	System Chipset- Intel i7 7700
•	System Memory- 2x DDR4 SO-DIMM 2133/2400 mm MHZ, up to 32GB (up to 16GB per SO-DIMM)
•	Storage- 256GB SATA
•	Ethernet- 4x Intel-Based Gigabit Ethernet
•	Display Interface- LVDS
•	Watchdog Timer- Software programmable supports, 1~255 sec system reset
•	Active area- 476.64(H) 268.11(V)
•	Resolution- 1920 x 1080
•	Screen Ratio- 16:9
•	Material- 5 wire Res. Touch screen with glass+ITO Film
•	(EMI Shielding conductive with 5-10 ohm)
•	I/O Interface- 4 x Ethernet ports,
                                 4 x USB Ports,
                                 1 x RS422 port
•	Display Colors- 16.7 M True Colors
•	Dot Pitch- 0.24825 (H) x 0.24825 (V)
•	Contrast Ratio- 1000:1
•	Brightness- 500 cd/m2
•	Viewing Angle- 85 (H) /89 (V)
•	User controls- PWR, Menu, Left, Right, Up & Down
•	Connector- 1 x Power Input,
                             4 x Ethernet ports,
                             4 x USB Ports,
                             1 x RS422 ports
•	Installed Configuration- 1 x 7th Generation Intel Core i7 Processor- 3.6Ghz,
                                                   2 x 16 GB DDR4,
                                                   1 x 256 GB Solid State Hard Disk Drive,
                                                   1x Windows 10 OS,
                                                   1 x SLP-88-461-USB Keyboard (I-key),
                                                   1 x 50mm Trackball ( NSi Belgium),
                                                   Dimension: 540(W)X360(D)X530(H)

•	POWER-
                   Power Supply: 230VAC, 50Hz
                   Power Consumption: 130 Watts Max

•	OPERATOR CONSOLE- Backlit Keyboard has a sliding-type desk with a standard USB connection connector Trackball with USB.

•	INDICATOR PANEL- LEDs, Reset Switch, buzzer, fuse

•	COOLING- Forced air cooling using fan

•	EXHAUST- Vents with honeycomb EMI filter

Applications-
•	Military Applications
•	Naval Applications
•	Airborne Applications
•	marines operations

Features-
•	Built-in 21.5” Display
•	High Resolution (1920 x1080 FHD)
•	LED Backlight
•	Intel Core i7 Processor
•	Compact Design
•	MIL Grade Circular Connector
•	Screen Size & Type- 21.5” TFT-LCD with WLED backlight
•	Touch screen- 5 Wire Resistive with ITO coating
•	Brightness- 400 cd/m2 typical
•	Screen Aspect ratio- 16:9
•	viewing angle- 178° vertical & 178° horizontal
•	Resolution-1920 x 1080 Pixels FHD
•	Contrast ratio- 1000:1
•	Display colour- >16.7 Million
•	Other controls- Front panel OSD control buttons
•	Motherboard- COM Express based
•	Processor- Intel core i7 3.0GHz or above
•	Graphics- Intel Gen 9 LP Core Architecture with 4 GB RAM.
•	Memory- 32 GB RAM
•	Storage- 1TB SSD, MLC, Industrial Version
•	Serial Ports- 1x RS232
•	USB Port- 3 x USB 2.0 or higher
•	Ethernet Port- 2 x 10/100/1000 Base T-Ports
•	Audio- Intel HD Audio Integrated
•	Operating System- Windows 10 & Linux RHEL 7.x (Dual OS pre-loaded with driver for all on-board devices and touch Interface)

Rugged LCD displays have been around for a fairly long time and their uses range from aiding in military and marines operations to the retail, restaurant, hospitality, and medical industries.

Features-
•	Built-in 24” Display
•	16:10 Aspect ratio
•	High Resolution(1920x1200)
•	Wide Viewing angle
•	High Contrast ratio
•	Brightness- 300 cd/m2 typical
•	Pixel Dimension 0.27 x 0.27 mm
•	Contrast Ratio- 500:1
•	Input- VGA, DVI-1, Power supply, USB
•	Remote Control- RS-232 Port
•	Weight- 9.5kg
•	EMI/EMC- MIL-STD 461E/F
•	Vibration- Airborne- 2g MIL-E-5400T
•	Shock- MIL STD-810, Light Weight
•	FCC- FCCA

Applications-
•	Military Applications
•	Naval Applications
•	Airborne Applications
•	marines operations

Rugged LCD displays have been around for a fairly long time and their uses range from aiding in military and marines operations to the retail, restaurant, hospitality, and medical industries.

Technical Specifications-
•	Built-in 3.5inch TFT Display
•	4:3 Aspect Ratio
•	High Resolution
•	High Contrast Ratio
•	High Brightness
•	LED Backlight
•	Screen Size- 3.5” TFT LCD
•	Brightness- 1000nits
•	Typical Viewing angle- 50deg Horizontal, 35deg Vertical
•	Resolution- 640 x 480 Pixels (VGA)
•	Aspect Ratio 4:3 (H:V)
•	Contrast ratio- 500:1

Environmental Specifications-
•	EMI/EMC- MIL STD 461E
•	BUMP- As per jss-55555
•	Vibration- As per jss-55555
•	Shock- As per jss-55555

Features-
•	They’re capable of lasting approximately 30,000 hours with continuous use for about 10 hours per day (that’s the equivalent of about 8 years)
•	Touchscreen LCD displays won’t overheat if they’re left on for long periods of time, which is ideal for environments and applications that require ongoing usage (e.g., military and marine ops, retail displays, restaurant digital menus, medical facilities, etc.)
•	Designed and manufactured with high performance standards to withstand extremely harsh weather and usage conditions
•	Dustproof and waterproof to prevent miniscule elements from causing internal damages
•	Sunlight readability and extensive brightness adjustment capability to facilitate usage in all lighting conditions
•	They’re completely shock- and vibration-proof to protect the internal mechanisms from damage caused by external elements
•	They can tolerate a wide range of temperatures from below freezing to extremely hot, depending on the environment

Applications-
•	Military Applications
•	Naval Applications
•	Airborne Applications
•	marines operations

EMP shielding racks are designed to protect major data storage units, communication equipment, and other network devices in any place where EMP protection solution is needed. Features Designed to meet International and Military Standards.

Technical Specifications-
•	BAND FREQUENCY: 10kHz ~ 1GHz (customizable up to 18GHz)
•	DIMENSION: 2212(H) x 712(W) x 900 mm (D)
•	SIZE: 40U, Standard 19-Inch Rack
•	WEIGHT: approx.300kg or less


Features-
•	External dimension of rack: 2212(H) x 712(W) x 900 mm (D) as per drawing.
•	Rack colour: Polyurethane paint as per PS 613 / 616. Color- Olive Green (Matt Finish).
•	Material prefabricated 2mm galvanized steel panels with conductive mesh gasket.
•	Rack is capable for carrying 500 kg weight of equipment.
•	19" rack mounting angles at both sides (front, rears intermediate).
•	Maximum equipment chassis width 450mm to be accommodated.
•	Air ventilation honeycomb panels with 2 nos of exhaust fans (200 cfm each - top and bottom of the rack).
•	Rack have front single leaf double knife edge door with copper beryllium contacts, clear opening of 2000mm high x 500 mm wide with manual latching mechanism having external handle.
•	4 No.of shock mounts are placed in between base structure & rack.
•	4 Nos. of lifting eye bolts are assembled on top of the side.
•	2 Nos. of cable tray (100W x 25H x 1.6 thick) on the rear side of the rack running to entire height of the rack.
•	Copper earthing strip of 25x3 for entire height with 5mm hole at 40 mm spacing earthing connection earthing strip to the external lug on chassis along with M10 earth studs.
•	Lamp to be provided at the front side with front door operated limit switch.

Applications-
•	Military Applications
•	Naval Applications
•	Airborne Applications

A rugged display is a panel mount display. The main characteristic is that it has an excellent flat panel display with an LVDS transmission interface and can be used for landscape applications.

Rugged LCD Display 5 INCH is a color active matrix TFT (Thin Film Transistor) LCD (Liquid Crystal Display) display. The main characteristic is that it has an excellent display performance driven by a pure Digital LVDS (Low Voltage Differential Signaling) interface assembled in a compact & slim LED backlight unit. Its outstanding performance high brightness, super wide viewing angle, and ultrahigh contrast ratio makes this display very suitable for terminal and video application. wide format display suited for Army application (eg. Vehicle wheeled and tracked) FOR Ground Level.

Environmental Performance -
•	Front-bonded LCD panel
•	Fanless
•	Extremely broad operating temperature range
•	Low power consumption

Optical Performance -
•	High brightness over the operational temperature range
•	Low reflection
•	Sunlight view ability & readability.

General Performance -
•	Compactness, lightweight
•	Ease of maintenance
•	Ease of implementation
•	High reliability

The 6.5" Rugged display consists of a 6.5" Color Active Matrix Liquid Crystal Display with an integral LED backlight system. The matrix employs amorphous silicon thin film transistor as an active element. The TFT LCD panel structure is injected liquid crystal material into the narrow gap between the TFT array glass substrate and a color filter glass substrate. The display has a wide/symmetrical viewing angle. It is a Transmissive type display operating in the normally black mode. This TFT LCD has a 6.5-inch diagonally measured active display area with XGA resolution (1024x768). Each pixel is divided into Red, Green, and Blue sub-pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is determined with a 6-bit greyscale signal for each dot, thus presenting a palette of more than 262,144 colors. The TFT LCD panel used for this module is a low reflection and high color saturation type.

The TFT array as an electro-optical switch regulates the amount of transmitted light from the backlight assembly when it is controlled by the data signals. Color images are created by regulating the amount of transmitted light through the TFT array of red, green, and blue dots.

6.5" Rugged display is a panel mount display. The main characteristic is that it has an excellent flat-panel display and can be used for both portrait and landscape applications.

Features-
•	They’re capable of lasting approximately 30,000 hours with continuous use for about 10 hours per day (that’s the equivalent of about 8 years)
•	Touchscreen LCD displays won’t overheat if they’re left on for long periods of time, which is ideal for environments and applications that require ongoing usage (e.g., military and marine ops, retail displays, restaurant digital menus, medical facilities, etc.)
•	Designed and manufactured with high performance standards to withstand extremely harsh weather and usage conditions
•	Dustproof and waterproof to prevent miniscule elements from causing internal damages
•	Sunlight readability and extensive brightness adjustment capability to facilitate usage in all lighting conditions
•	They’re completely shock- and vibration-proof to protect the internal mechanisms from damage caused by external elements
•	They can tolerate a wide range of temperatures from below freezing to extremely hot, depending on the environment

Applications-
•	Military Applications
•	Naval Applications
•	Airborne Applications
•	marines operations

The Rugged 8.4" LCD Display is designed with a wide viewing angle: wide operating temperature and long-life LED backlight is well suited to be the display unit for industrial applications.

To take care of shock and vibrations the sub-systems are firmly secured to prevent their failures during shock and vibration. The chassis of the system is designed and manufactured to take care of high levels of shock and vibrations. For EMI hardening purposes, special-purpose EMI gaskets, and EMI line filters are used apart from the design techniques that contribute to making an EMC system

Technical Specifications-
• 8.4" LCD Display
• MIL Circular Connectors for Power
• Power Supply input: DC 9-36 V
• EMI/EMC: MIL-STD-461D

The Rugged 8.4" LCD Display unit measures 225(H) x 245(W) x 92(D) mm excluding rear panel connectors housing the 8.4" TFT Display with Resolution of 800 x 600, VGA Interface, DC-DC Power Supply, MIL Circular Connector and EMI Filter etc.

DC-DC Power Supply used in the Rugged 8.4" LCD Display in order to cater to the power requirements of various sub-assemblies. This power supply takes 9-36 VDC input and delivers output voltages of +12VDC. The power supply input is fed through an EMI filter.

Features-
•	They’re capable of lasting approximately 30,000 hours with continuous use for about 10 hours per day (that’s the equivalent of about 8 years)
•	Touchscreen LCD displays won’t overheat if they’re left on for long periods of time, which is ideal for environments and applications that require ongoing usage (e.g., military and marine ops, retail displays, restaurant digital menus, medical facilities, etc.)
•	Designed and manufactured with high performance standards to withstand extremely harsh weather and usage conditions
•	Dustproof and waterproof to prevent miniscule elements from causing internal damages
•	Sunlight readability and extensive brightness adjustment capability to facilitate usage in all lighting conditions
•	They’re completely shock- and vibration-proof to protect the internal mechanisms from damage caused by external elements
•	They can tolerate a wide range of temperatures from below freezing to extremely hot, depending on the environment

Applications-
•	Military Applications
•	Naval Applications
•	Airborne Applications
•	marines operations

Features-
•	 Universal AC Input / Full Range
•	 High Efficiency
•	 Protections: Short Circuit / Overload
•	 Over voltage
•	 Compact Size
•	 LED Indicator for Power ON
•	 Customized Solution
•	Output DC Voltage- 24 V
•	Output Current- 3.5A
•	Output Power- 84W
•	Input Voltage Range- 80 ~ 264 1P VAC Full Range
•	Input Frequency- 47 ~63 Hz
•	Input Current- 0.90 A, Typical at 230VAC, full load
•	Inrush Current Protection- Yes (Thermistor Controlled)
•	Connector Type- D38999 MIL Grade
•	Number of Outputs- 1
•	Product Type- AC to DC Power Supply
•	Efficiency- Up to 86%
•	Line Regulation- ~48mV
•	Load Regulation- ~48mV
•	Ripple (mvp‐p)- 250Max @ 15% Load
•	MTBF- 15,732,975 Hr @ 25°C
•	Dimensions- 180mm x 125mm x 55mm
•	Safety Approvals- UL60950‐1, C‐UL (CSA60950‐1), EN60950‐1, EN50178, Complies with IEC61000‐3‐2 (Class A)

Airborne operator console is the main operator cum display console of the entire LFDS (Low Frequency Dunking Sonar) Sonar system apart from the display monitor and panel PC it consists of signal and display Processor ATR, Transmitter ATR, Recorder Box, Intercom, WRC, Recorder, Homing Indictor, VHF Indicator, Circuit Breakers, integrated keyboard and their associated accessories.

Sonobuoy cum Receiver rack is two tier rack having twelve circular holes for mounting of Sonobuoy. Sonics rack is integrated with VHF Rx ATR, Homing Rx, ATR, 12 Numbers of sonobuoys and drop-marking switch. In additional to these items there are multiple I/O connector on the front panel of the ATR.

The use of pesticides in agriculture is very important for edible items and it will be so easy if people use intelligent machines such as UAVs. PAS-Agri-10L is the best in the segment of 10-liter pesticide spraying drones. PAS-Agri comes with a solid Frame that provides high strength in difficult manoeuvres while carrying the pesticides. The time taken by PAS- Agri to spray the pesticide is just 10% of manual spraying time. PAS- Agri comes with lots of features to make it simple and intuitive to use. PAS- Agri UAV has multiple fail-safe features by which we assure the safety of our farmers and their crops, like a return to home at low battery, return to home after RC link lost, and many others. Enhanced training is provided for proper understanding of UAVs.

FLIGHT PARAMETERS -
Total Weight – 10.5 kg (without battery 23.5kg with battery, full loaded)
Standard Take-off Weight – 23.5 kg
Max Take-off Weight - 25 kg
Hovering time - 10 min (23.5kg take-off weight) * 25min (13.5kg take-off weight)*
Max Operating Speed - 8 m/s*
Max Flying Speed - 10 m/s*

SPRAY SYSTEM –
Liquid Tank Volume – 10L
Number of Nozzle – 4
Spraying Span – 3.5-4m
Theoretical Operating Efficiency – 200,000m /day (8hs, 6 sets of batteries)
Max Spraying Speed – 3.5L / min

WEIGHT BUILD-UP –
Parts – Weight (kg)
Frame – 4 Kg Approx.
Battery (2) – 3kg (1.560kg Each)
Hobby Wing X8 Combo (4x) – 4.160 Gm (1.040 Kg Each)
Flight Controller – 0.100kg
Total – 11.26 Kg

Company - Paras Aerospace
Contact -  info@parasaerospace.com

The use of pesticides in agriculture is very important for edible items and it will be so easy if people use intelligent machines such as UAVs. PAS-Agri-5L is the best in the segment of 10-liter pesticide spraying drones. PAS-Agri comes with a solid Frame that provides high strength in difficult manoeuvres while carrying the pesticides. The time taken by PAS- Agri to spray the pesticide is just 10% of manual spraying time. PAS- Agri comes with lots of features to make it simple and intuitive to use. PAS- Agri UAV has multiple fail-safe features by which we assure the safety of our farmers and their crops, like a return to home at low battery, return to home after RC link lost, and many others. Enhanced training is provided for proper understanding of UAVs.

SPECIFICATION –
Dimension – 819 X 800 X 540 mm (arm unfolded, without propeller)
Diagonal Wheelbase – 1145 mm

FLIGHT PARAMETERS –
Standard take-off weight – 15 kg
Max take-off weight – 17 kg
Hovering Time – 20 min
Max operating speed – 8 m/s
Max Flying Speed – 10 m/s

SPRAY SYSTEM –
Liquid tank volume – 5 L
Number of Nozzle – 4
Spraying Span – 3.5 – 4m
Theoretical Operating Efficiency – 200.000m/day (8hs. 6 sets of batteries)
Max spraying – 3.5L / min

Company - Paras Aerospace
Contact -  info@parasaerospace.com

With an innovative and convenient VTOL design, the Angular Rotor is both a rugged and versatile UAV, making it an excellent solution for military applications. The Angular Rotor has a maximized efficiency with up to 60 minutes longer flight, 2KG payload capacity, high maneuverability with hovering mode, and resistance to severe weather conditions. With reliable technology, it has robust control and failsafe operation with a proprietary autopilot. Autonomous take-off and & landing even in unstructured terrain. Protection from strong electromagnetic fields with the absence of bulky launchers or capture devices.
END-TO-END INTEGRATED SOLUTION-
In-house developed hardware and software.
Multiple sensor payloads from RGB cameras to LIDAR, and much more.
Proprietary 2-in-1 GCS software for intuitive flight planning and convenient terrain tracking.
World-class service throughout mode the entire product life cycle.
Training and certification for end-users.

SPECIFICATIONS -
Type - Vertical take-off and landing (VTOL) aircraft
Wingspan - 1620 mm (5.3ft)
Number of rotors - 4
Maximum take-off weight (MTOW) - 7 kg (15.4 lb)
Maximum payload weight - 2 kg (4.4 lb)
Take-off Method - Vertical (fully autonomous)
Landing Method - Vertical (fully autonomous)
Deployment time - 2 min Up to 60 min
Endurance – Up to 60 min
Flight Distance - Up to 60 km (37.3 mi)
Maximum flight Speed - 120 km/h (74 mph)
Cruise speed - 65-72 km/h (40-45 mph)
Hovering in Copter mode - Yes (up to 20 min)
Maximum telemetry range - 40 km (24.9 mi)
Maximum flight altitude above sea level - 4,500 m (14,763 ft)

Company - Paras Aerospace
Contact -  info@parasaerospace.com

The Telescopic Sight AP37C is a robust weapon mountable lightweight shockproof telescopic sight with the ability to engage targets at large distances. AP37C is wholly designed and developed in India owing to the “Make in India” program. Sight is parallax free for a considerable target distance.

Features -
1/2 MOA.
Edge-to-Edge Image
Optics hold zero.
Etched glass Reticle.

Technical Specifications -
 • Optical Magnification of 5x
 •  FOV - 4.5°

The Telescopic Sight AP37 is a robust weapon mountable lightweight shockproof telescopic sight with the ability to engage targets at large distances. AP37 is wholly designed and developed in India owing to the “Make in India” program. Sight is parallax free for a considerable target distance.

Features -
1/2 MOA.
Edge-to-Edge Image.
Optics hold zero.
Etched glass Reticle.

Technical Specifications -
 • Optical Magnification of 4x
 •  FOV    4.5°

AR64 is a dual-mode fusion thermal imager. It adopts infrared and low-light fusion and achieves a unique advantage over existing units in the market today. The imaging resolution is very high allowing the ease to recognize a single object. It also has the advantage of observation through the glass. Meanwhile, the device is also embedded with dual wave-length fusion and focus to magnify the key target at a very high definition for verification.

Features -
 • 4 different Image Modes - IR Colour/Fusion IR/Fusion Thermal/Fusion Colour
 • Built-in Display - 720X540, LCOS
 • Image storage - Built-in 16GB SD card, can store about 2000 still pictures
 • Fusion imaging distance - Fusion: 1.8m X 0.5m
   Person - Detection: > 4000m; Identification > 1500m
 • No calibration is needed as there is no shutter

Application -
1. Searching the animals or humans in the countryside in dark conditions
2. Collecting the evidence by police in the low light city environment
3. Night patrol by soldiers in the war or any other tasks
4. Rescue task or outdoor activities

Technical Specifications -
Lens of IR channel: 25mm
FOV: 17° x 13°
Resolution: 384 x 288
Pixel Size: 17 µm
Frame Rate: 30 Hz
Battery Life: 8 hours
Weight: 503.5 g
Dimension: 175 mm x 88.7 mm x 48.2 mm

The ARF 100 Tactical light with LRF_PISTOL Light enables operators to engage targets on a battlefield or during close-quarter combat in low-light and no-light conditions. The new ARF 100 combines the Visible Green LASER only (No IR) and White Light Illuminator of the ARF 100, with a single receptacle end cap for remote switch operation.

Features -
 • 400 Lumen White LED Light
 • Class IIIa 532nm Green Aiming Laser
 • Class I 850nm Infrared Aiming Laser
 • Eye Safe 850nm IR LED Illuminator
 • Integrated Picatinny Rail Mount

 • Programmable right and left fire buttons
 • Red or Green visible aiming laser, IR laser, IR illuminator & white light
 • Co-aligned visible & IR aiming lasers
 • Fully adjustable windage and elevation
 • Integrated adjustable Picatinny mount
 • Powered by two CR123A Batteries
 • Quick-release battery latches
 • Available in Green (79050) and Red (79040) Lasers
 • Bright white light and IR illuminator sits below the laser pointers
 • Recoil-resistant design ensures reliable performance

Technical Specifications -
Color	Black
Wavelength - Visible Red Laser        640mW
Wavelength - IR Laser        840 nm
Wavelength - IR Illuminator        840 nm
Range/Visibility (Night/Day)* - Visible Red Laser        25 m
Range/Visibility (Night/Day)* - IR Laser	1400 m
Range/Visibility (Night/Day)* - IR Illuminator	1400 m
Temperature	-40° C to +65° C
Battery - CR123AMaterial Aircraft aluminum
Weight (with battery)	153 g (5.4 oz)
Dimensions - 8.7 x 4.1 x 3.35 cm (3.46 x 1.62 x 1.32 in.)
Waterproof - Submersible to 5 m
Mount Standard pistol or M1913 rails

Aspheric lenses have non-spherical shapes and have a more complex front surface. These Lenses are used when magnifying tiny or distant objects to help see more details. The main advantage of aspheric lenses is their ability to correct spherical aberration. Aspheric lenses allow optical designers to correct aberrations using fewer elements than conventional spherical optics because the former gives them more aberration correction than multiple surfaces of the latter.

Aspherical lenses have complex curved surfaces, where the radius of the curvature changes according to the distance from the optical axis. The use of aspherical lenses in optical systems enables the optical designers to use fewer elements than conventional spherical optics. This allows for a more compact design, lower weight and exceptional performance.
By combining high precision CNC polishing and 3D non-contact measurement metrology techniques, II-VI produces very high-quality aspherical lens for a wide variety of applications.

Technical Specifications:
Please refer the image for technical specification.

Features:
•	Complete in-house manufacturing capability enables control of all manufacturing steps
•	Ultra-precise and 3D non-contact measurement technique
•	Quick-turn service on new products
•	Capacity and flexibility to scale

Application:
•	Aspheric lenses allow optical designers to correct aberrations using fewer elements than conventional spherical optics
•	Aspheric lenses focus light to a small point, creating comparatively no blur and improving image quality

Complete Flight Control System with certified Hardware and Software offers cutting edge Cockpit Systems for Aviation Platforms. Suitable for Military and Civil Aviation requirements. Approved for all classes of aircraft, the uniquely customizable open-architecture systems dramatically reduce integration costs and schedules for both OEM and retrofit applications.

Analog and Digital Autopilots
3D Synthetic Vision EFIS
Autopilot and Stability Augmentation System
Sensors & Components
